Elastomer Mill | Soft Rubber Mill
Gu'an Machinery is a factory engaged in the design and manufacture of rubber/EVA/leather grinding machinery. After years of research and development and experiments, the company has successfully developed an EVA scrap mill/ultrafine rubber mill/sponge mill Powder machine and leather grinding unit and other ultra-fine plastic grinding unit. We can design all kinds of non-standard machinery and equipment according to the specific requirements of customers. Main supply: rubber mill, plastic mill, silicon powder machine, disc mill, powerful crusher, silica gel mill/plastic mill, PE pulverizer, PVC pulverizer, PP pulverizer, ABS pulverizer, PS pulverizer, sponge and leather pulverizer, etc.
Elastomer Mill | Soft Rubber Mill
main feature:
|
|
|||||
| 1.The new grinding disc design has higher output, stronger wear resistance and twice the life of ordinary discs; | |||||
| 2.Using newly designed special bearings, high speed is more stable; | |||||
| 3. Easy to install and maintain, easy to clean; | |||||
| 4.The grinding process is completely closed, and there is no dust leakage; | |||||
| 5.Fully automatic, automatic feeding, discharging and sorting; | |||||
| 6.The adjustment of the grinding gap is simple, just use the feeler gauge and adjusting bolt to adjust accurately; | |||||
| 7.The cooling system of the main engine adopts the combination of air and water for cooling. | |||||
| 8.The design is reasonable, the cross section of the grinding chamber is small, and the material will be caught immediately as soon as it enters, | |||||
| Grind it finely, and then remove it quickly to avoid the decomposition of the material due to heating. | |||||
| 9.The size of the grinding powder can be adjusted, and it can grind 10-120 meshes, which is easy to adjust; | |||||
| 10.This series has disc type and knife grinding type to choose from, please consult our company's professionals for selection; | |||||
| 11.Factors affecting the production capacity are: the size and mesh of the grinding powder, the material of the grinding material; the feed size is 5-8mm; | |||||
The use of Gu'an mill grinder pulverized material grinder:
This machine absorbs and introduces domestic and foreign technology and is carefully developed; it can be widely used in powder processing of various natural rubber, synthetic rubber, plastics and other materials.
The structure principle of Gu'an Grinder Grinder Grinder Grinder:
The machine consists of two main grinding machines, a cyclone collection mechanism, and a screening machine. The main machine consists of a frame, a main motor, a stepless variable speed motor, a feeding mechanism, an adjustment mechanism, and a pair of movable grinding discs and fixed grinding discs. The basic principle is to cut and grind the material through the relative motion of the two discs to achieve the purpose of pulverization. Air and water cooling are used to effectively control the pulverization temperature to ensure the physical properties of the powdered materials. The feeding mechanism adopts infinitely variable speed, which can adjust the corresponding feeding speed according to different materials, so as to achieve better product requirements. The machine has the advantages of compact structure, low noise, high output, low energy consumption, simple operation, convenient disassembly and assembly, no environmental pollution, and uniform powder fineness.
Elastomer Mill | Soft Rubber Mill
technical parameter SPECIFICATIONS
| 型號 Model | 磨盘直径diameter | 主机功率（kw) Motor | 风机功率（kw) Motor | 振动筛功率（kw) Motor | 外形尺寸（l*w*h) Dimensions | 产量（kg/h) Throughput | 重量（kg） Weight |
| GFM-400 | D300 | 22 | 3 | 0.75 | 1700*1500*3400 | 120-200 | 1200 |
| GFM-500 | D500 | 37 | 4 | 1.1 | 1800*1600*3600 | 180-400 | 1600 |
| GFM-600 | D600 | 45 | 5.5 | 1.5 | 1900*1700*3800 | 250-600 | 2200 |
| GFM-800 | D800 | 75 | 11.5 | 2.2 | 2300*1900*4200 | 450-800 | 3500 |
| 產品規格.外形.顏色若有變更，恕不另行通知。We reserve the right to change specif ations without prior notice | |||||||
